Request an On-Site Substrate Inspection & Technical Quote
Connect directly with Qatar Epoxy’s estimation and engineering team. We deploy mobile diagnostic crews to facilities across Doha, Industrial Area, Birkat Al Awamer, Mesaieed, Ras Laffan, and all Qatar municipalities.
Direct Contractor Engagement
Project Scope & Site Diagnostic Request
Provide project details below to receive an itemized commercial proposal, material submittal package (MAR), or to schedule an on-site concrete moisture survey.
What Happens During a Qatar Epoxy Site Inspection?
We do not glance at a floor and quote a flat rate. Our technical engineers conduct six non-destructive and quantitative diagnostic tests to engineer an unshakeable proposal.
In-Situ Moisture Testing (ASTM F2170)
We drill electronic probe holes to measure internal slab relative humidity and surface moisture vapor emission rates (MVER), establishing whether an epoxy moisture-barrier primer is mandatory.
Schmidt Hammer Rebound (ASTM C805)
We test concrete compressive hardness across multiple grid points to verify minimum 25 MPa soundess, identifying weak or powdery zones requiring consolidating epoxy primers.
Surface Tensile Adhesion (ASTM C1583)
We verify the cohesive tensile strength of the concrete surface layer to ensure it exceeds the 1.5 MPa threshold required to prevent shear debonding under heavy reach truck torque.
Contamination & Laitance Mapping
We test for hydrocarbon, oil, or brake fluid ingress depth and verify whether wax curing membranes are present, specifying mechanical scarification or oil-tolerant priming.
Joint & Structural Crack Survey
We map dynamic construction joints, control relief joints, and static cracks, determining the exact linear meterage of structural V-grooving and flexible polyurea sealant required.
Elevation & Drainage Verification
For wet processing or food manufacturing facilities, we verify slab drainage gradients, stainless trench tie-ins, and wall-floor junction geometry for 75mm radius coved skirtings.
Subcontractor Approval Documentation We Supply
For main contractors and project consultants in Qatar, we provide full engineering submittal packages aligned with Ashghal and QCS 2018 standards.
| Document Type | Standard Coverage | Turnaround Time | Approval Value |
|---|---|---|---|
| Material Approval Request (MAR) | Manufacturer TDS, SDS, third-party lab test reports, and factory ISO certificates | 24 – 48 Hours | Guarantees 100% material compliance with project engineering specifications |
| Method Statement (MOS) | Step-by-step surface preparation, mixing protocols, application thickness, and curing controls | 24 – 48 Hours | Defines clear procedural sequence for site supervisory engineers |
| Inspection and Test Plan (ITP) | Hold points, inspection criteria, acceptance metrics (CSP, MVER, pull-off adhesion) | 24 – 48 Hours | Establishes formal sign-off stages for consultant QA/QC inspectors |
| On-Site Benchmark Mock-Up | 20 m² to 50 m² full system mock-up demonstrating color, gloss, and slip texture | Scheduled with Main Contractor | Provides visual and physical approval benchmark before full mobilization |
Direct Mobile Service Coverage Across All Qatar Municipalities
Our self-contained mobile equipment trailers and certified application technicians operate continuously throughout Qatar.
| Municipality / Zone | Key Industrial Districts | Typical Operational Scope | Mobilization Timeline |
|---|---|---|---|
| Doha Municipality | Industrial Area (St 1-52), Ain Khalid, Ras Bufontas | Warehouses, automotive workshops, manufacturing, logistics | Immediate / 24 Hours |
| Al Wakrah Municipality | Birkat Al Awamer, Al Wukair Logistics, Mesaieed Port | High-bay logistics, cold stores, food processing, heavy transport | Immediate / 24 Hours |
| Al Rayyan Municipality | New Industrial Area, Al Sailiya, Education City | Commercial vehicle depots, assembly plants, institutional facilities | Immediate / 24 Hours |
| Al Wakrah (MIC) | Mesaieed Industrial City Petrochemical Zone | Secondary containment bunds, acid-resistant Novolac, workshops | Subject to QP Gate Pass Coordination |
| Al Khor / Al Thakira | Ras Laffan Industrial City (RLIC), Al Khor Light Industrial | LNG support facilities, avionics cleanrooms, water treatment | Subject to RLIC Gate Pass Coordination |
| Al Daayen / Umm Salal | Lusail City, Umm Salal Mohammed Industrial Area | Multi-level car parks, commercial retail, food distribution | Immediate / 24 Hours |
| Al Shamal / Dukhan | Dukhan Oilfield & Western Industrial Sectors | Oilfield pump stations, chemical storage, utility rooms | Scheduled Mobilization |
Speak Directly With Our Engineering Desk
Need an urgent response for a project tender, consultant inquiry, or facility shutdown schedule? Contact our team now.
